Diamondback Sync'r Carbon 29
Details
The most bomber yet of our progressive hardtail mountain bikes...in a 29er!
Easy to pedal up, bomber on the way down, playful the whole ride. See what all the fuss is about with our most progressive hardtail that now comes as a 29er. An all-new monocoque carbon frame design features a tapered headtube and Boost rear spacing for increased stiffness. Burly 29x2.5-inch tires roll on tubeless-compatible Blanchard wheels, providing a cush feel while smashing down chundery trails. A 140mm travel Fox 34 Float Performance fork can handle aggressive riding and big moves, while Shimano hydraulic disc brakes keep you on your line. Thanks to the SRAM GX Eagle drivetrain, your legs will stay fresh on the climbs so you can shred as hard as you want all the way down.
- Monocoque carbon frame features internal cable routing for a clean look and Boost spacing for added stiffness
- 140mm travel Fox 34 Float Performance fork designed for aggressive trail riding
- SRAM GX Eagle drivetrain provides an ultra-wide gear range and the simplicity of a single chainring
- Shimano hydraulic disc brakes offer great stopping power
- 29 inch tires on tubeless-compatible DB Blanchard wheels for more traction and control
Specs
| Frame | Sync'r Monocoque Carbon, Asymetrical Chainstays, Internal Cable Routing, Tapered Headtube, Euro Standard Threaded BB, ISCG-05 Tabs, Internal Dropper Post Ready, 148x12mm Boost Hub Spacing, 29x2.4" as well as 27.5x2.6 compatable, Post Mount Disc, w/ Replacable Hanger |
|---|---|
| Fork | Fox 34 Performance Float, 140mm of Travel, Grip 3 POS, 15mm Thru Axle, for 29x2.4" can also fit **27.5x2.6" wheel / tire combinations |
| Headset | FSA No-57E Taper 1.5 /1-1/8" Standard Cups, Sealed Cartridge |
| Axles |
Front: 110 x 15mm Rear: 148 x 12mm |
| Rims/Wheels | Diamondback Blanchard 32R, Tubeless compatible, 32h |
| Hubs |
Front: 32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount Rear: 32h Alloy, Boost 148x12mm Thru-axle, 5 Sealed Cartridge Bearing, for SRAM XD Cassette, w/ CNC Disc Mount |
| Spokes | 14g Stainless Steel |
| Tires | Maxxis Minion DHF 29x2.5" EXO, TLR, Folding / Maxxis Minion DHR 29x2.4" EXO, TLR, Folding |
| Crankset | SRAM NX |
| Chainrings | 32T Eagle Chainring |
| Bottom Bracket | Truvativ Powerspline |
| Chain | SRAM GX Eagle, 12 Speed |
| Rear Derailleur | SRAM GX Eagle, 12 Speed |
| Cassette/Rear Cogs | SRAM XG1275 Eagle, 12 Speed, 10-50T |
| Shifters | SRAM GX Eagle 12 Speed X-Actuation Trigger |
| Handlebars | Race Face Æffect 35, 20mm Rise, 780mm Wide, 35mm Bar Bore |
| Tape/Grips | New DB "Flanged" Lock-on, 135mm Silcone |
| Stem | Diamondback "Tec", 35mm Reach, 35mm Bar Bore |
| Brake Levers | Shimano MT501 Hydraulic |
| Brakes | Shimano MT501 Hydraulic Disc, w/ 180mm Front and 160mm Rear Rotors |
| Pedals | DB4L Alloy Platform, Sealed Cartridge Bearings w/ Replaceable Pins |
| Saddle | DB Sync'r Saddle |
| Seat Post | X-Fusion Manic Dropper Post, 125mm (S,M) / 150mm (L,XL) of travel |
| Accessories & Extras | Tool Kit, **double check tire fitment as tire sizes can be different by brand. |
* Subject to change without notice.
